Gummy Candy Packing Machine丨Fully Automatic Chocolate 丨Snacks Premade Bag Doypack Packing Machine
- Model
- TOPY-MDPL
Item specifics
- Machine name
- Gummy Candy Packing Machine
- Bag width
- 80-300mm
- Bag length
- 100-450mm
- Bag type
- doypack bag, stand up zipper pouch, gusset bag
- Voltage
- 110/220/240/380/415 V
- Pneumatic parts
- Eurovac Vacuum Pump from Taiwan
- Machine Material
- SS#304
- Speed
- 15-30bags/min
- Function
- Bag opening, filling, sealing, date coding
- Brand
- TOP Y MACHINERY
- Warranty
- 2years
Review
Description
Gummy Candy Packing Machine Advantage
Matched with high-precision multi-head weigher, this horizontal pre-made pouch packaging line is specially developed for gummy candies and functional candies. It perfectly solves common industry problems such as material sticking, extrusion deformation, center filling bursting, jamming, poor appearance and unstable weighing.
1. Gentle Low Feeding, No Broken or Burst Gummies
Gummy candies are soft and fragile. Vertical machines easily cause cracking and syrup leakage due to high drop impact. The horizontal gentle feeding design ensures zero-impact bag filling, fully protecting candy shape and greatly improving finished product yield.
2. Anti-stick Multihead Weigher Design
Optimized for high-sugar and sticky gummies. Custom anti-stick hopper prevents material sticking and residue. Stable weighing ensures highly consistent batch production.
3. Quick Changeover Design for Multi-flavor Production
All material contact parts adopt food-grade 304 stainless steel with detachable modular structure. Easy full cleaning without dead corners, effectively avoiding cross-flavor during frequent product switching.
4. Full Pouch Compatibility, Premium Sealing Effect
Compatible with all pre-made pouches such as stand-up zipper bags, window bags, frosted bags and flat bags. Tight and flat sealing provides excellent moisture-proof & fresh-keeping performance, preventing gummy softening and sticking.
5. High Automation, Cost & Labor Saving
Unmanned full-process operation: automatic bag picking, opening, dust removal, filling, sealing, coding and discharging. One machine replaces multiple workers with stable performance and low failure rate, perfect for long-term mass production.
Gummy Candy Packing Machine Features
1. Servo motor to control and high speed to work.
2. Easy to operate，adopt advanced PLC from Japan Mitsubishi, mate with touch screen and electric control system.
3. Automatic checking: no pouch or pouch open error, no fill, no seal. the bag can be used again, avoid wasting packing materials and raw materials.
4. Safty device: Machine stop at abnormal air pressure, heater disconnection alarm。
5. The width of the bags could be adjusted by electrical motor. Press the control-button could adjust the width of clips, easy operation and save time.
6. It matches with the glass safety door. The machine will stop working when you open the door. So that it could protect the safety of operators. At the same time, it could prevent dust.
7.Use the plastic bearing for liquid products to resist the rust.
8. The packing materials loss low, what this machine is used the preformed bag, the bag pattern is perfect and has a high quality of the sealing part, this improved the product specification
9. With different feeders changed to pack solid, liquid, thick liquid ,powder and so on
10. The packing bag suits in extensive range, suit for multi-layer compound, monolayer PE , PP and so on Preformed bag made by film and paper.
Gummy Candy Packing Machine Specifications
Model No. | TOPY-MDPL1 | TOPY-MDPL2 | TOPY-MDPL3 |
Bag Width | 80-200mm | 100-260mm | 150-300mm |
Bag Length | 100-300mm | 150-400mm | 180-450mm |
Packing Speed | 24-27bags/min | 20-24bags/min | 15-20bags/min |
Bag Type | Stand-up bag, pillow bag | ||
Power Supply | 110V/220V/380V/415V, 50/60HZ | ||
Pneumatic Parts | EUROVAC vacuum pump, Pneumatic component Airtac from Taiwan | ||
Applicable Products
Vitamin gummies, probiotic gummies, collagen gummies, fruit & vegetable gummies, bear gummies, center-filled gummies, functional health gummies and other sticky candy products.
Pouch Types (Pre-made Pouches)
Stand up Pouch, Flat Bottom Pouch, 3-Side Seal, 4-Side Seal，Pillow Pouch, Shaped Pouch，Quad Seal Pouch
